FIGURE

Fig. 1

ID

ZDB-FIG-160205-8

Publication

Etard et al., 2015 - Loss of function of myosin chaperones triggers Hsf1-mediated transcriptional response in skeletal muscle cells

Other Figures

All Figure Page

Back to All Figure Page

Fig. 1

Expression of unc45b mRNA in muscle mutants. unc45b mRNA expression in wild-type sibling (a) and unc45b mutant (b) embryos. unc45b mRNA expression in wild-type sibling (c) and sop mutant (d) embryos with a defective delta subunit of acetylcholine receptor. unc45b mRNA expression in wild-type sibling (e) and ache mutant (f) embryos encoding a defective acetylcholine esterase. unc45b mRNA expression in control (g) and titin morphant (h) embryos. With the exception of unc45b mutants (b) with a myosin folding defect, none of the other mutants with impaired muscle function (d, f, h) showed up-regulation of unc45b mRNA. Embryos were hybridized to unc45b antisense RNA. All embryos are 72 h old; anterior left, dorsal up. i Myosin content in different mutants compared with wild type. Western blot done with protein extracts from embryos 72 hours post-fertilization: titin mutant (hel-/-), unc45b mutant (unc45b-/-), hsp90a mutant (hsp90a-/-) and wild type (WT). Antibodies: F59 recognizing slow myosin, and γ-tubulin as a loading control

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Genome Biol.
