Fig. 1

Mitotic and early meiotic germ cells are present in the adult ovary. (A–D) RNA in situ hybridization and immunohistochemistry shows that dmc1 expressing cells (blue) are present in the adult ovary (A), and that these cells are also positive for γH2AX protein (brown), which labels cells containing double-strand DNA breaks (B). RNA in situ hybridization shows that sycp3 expressing cells are present in the adult ovary (C). (D) Mitotic germ cells are present in the adult ovary as vasa RNA positive germ cells (blue) co-labeled for phosphorylated histone H3 (PH3; brown). (E) BrdU⁺ Vasa⁺ <20 μm germ cells are present in the adult ovary. All images are from whole mount preparations. Scale bars: 50 μm (A–D), 20 μm (E). Stage Ia oocytes (Ia), stage Ib oocytes (Ib) and oogonia (oo).

Expression Data

Genes:	dmc1 sycp3
Antibodies:	Ab1-ddx4 Ab1-h2afx Ab3-h3
Fish:	WT
Anatomical Terms:	ovary germ line cell ovary oocyte stage I
Stage:	Adult

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 374(2), Beer, R.L., and Draper, B.W., nanos3 maintains germline stem cells and expression of the conserved germline stem cell gene nanos2 in the zebrafish ovary, 308-318, Copyright (2013) with permission from Elsevier. Full text @ Dev. Biol.
