Fig. 3

Identify plcg1 is indeed responsible for phenotypes of ldd239. ((A)–(F)) Plcg1 mRNA can rescue the ldd239 defect. Injection of plcg1 mRNA can restore the decreased mpx expression in mutant ICM region at 22 hpf compared with mutants ((C) and (D), black arrows). Simultaneously, deficient angiogenesis can also be rescued by overexpression of plcg1 ((E) and (F), black arrows). ((G) and (H), (K) and (L)) Plcg1 morphants have the same phenotypes as ldd239 mutants. Plcg1 morphants have a decreased mpx expression like ldd239 mutants ((G) and (H), black arrows) and also have a deficient angiogenesis marked by flk1 deficient expression ((K) and (L), black arrows). ((I) and (J)) WISH for l-plastin. Expression of l-plastin ((I) and (J)) has no change at 22 hpf in plcg1 morphants.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO4-plcg1
Knockdown Reagent:	MO4-plcg1
Observed In:	granulocyte differentiation myeloid leukocyte differentiation
Stage:	26+ somites

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 374(1), Jing, C.B., Chen, Y., Dong, M., Peng, X.L., Jia, X.E., Gao, L., Ma, K., Deng, M., Liu, T.X., Zon, L.I., Zhu, J., Zhou, Y., and Zhou, Y., Phospholipase c gamma-1 is required for granulocyte maturation in zebrafish, 24-31, Copyright (2013) with permission from Elsevier. Full text @ Dev. Biol.
