Fig. 2

Expression of Sycp3 in the zebrafish testis by immunohistochemistry. (A-F) Sections of the zebrafish testis immunostained with anti-Sycp3 antibodies. Spermatocytes shown are at the preleptotene (B), leptotene (C), zygotene-pachytene (D) and diplotene (E) stages. Green signals indicate Sycp3 and red staining indicates nuclei. (F) A section of testis was hybridized with an anti-sense probe for sycp3 and then stained with anti-Sycp3 antibody. Dark blue color indicates sycp3 mRNA and brown color (arrowheads) indicates Sycp3 protein. (G-I) Chromosome spreads immunostained with anti-Sycp3 antibodies. Spermatocytes shown are at the zygotene (G), pachytene (H), and metaphase (I) stages. Red signals indicate Sycp3, blue staining indicates nuclei, and green staining indicates phosphohistone H3 (pH3, an M phase marker). Bars, 20 µm (A) and 10 µm (B-I).

Expression Data

Gene:	sycp3
Antibody:	Ab1-sycp3
Fish:	WT
Anatomical Term:	spermatocyte synaptonemal complex
Stage:	Adult

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 11(5-6), Ozaki, Y., Saito, K., Shinya, M., Kawasaki, T., and Sakai, N., Evaluation of Sycp3, Plzf and Cyclin B3 expression and suitability as spermatogonia and spermatocyte markers in zebrafish, 309-315, Copyright (2011) with permission from Elsevier. Full text @ Gene Expr. Patterns
