Fig. 3

Terminal differentiation of intestinal goblet cells is affected in agr2 morphants.

Significant increases in immature Alcian blue-stained goblet cell numbers were detected in 104- (C, n = 46) and 120-hpf (G, n = 23) agr2 morphants compared to those in either 104- (A, n = 40) and 120-hpf (E, n = 30) wild type or in 104- (B, n = 41) and 120-hpf (F, n = 27) agr2–5 mmMO1 and 5 mmMO2-coinjected embryos. Inset shows a mature and an immature goblet cell. Comparison of both immature and mature goblet cell numbers among agr2 morphants, wild type or agr2–5 mmMO1 and 5 mmMO2-coinjected embryos at 104 and 120 hpf are shown (D, H). A Student′s t-test was conducted to compare immature goblet cell numbers in agr2 morphants with those in wild type or agr2–5 mmMO1 and 5 mmMO2-coinjected embryos. *p<0.001. Scale bars represent 100 μm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	AB + MO1-agr2 + MO2-agr2
Knockdown Reagents:	MO1-agr2 MO2-agr2
Observed In:	goblet cell
Stage Range:	Day 4 to Day 5
