FIGURE

Fig. 5

ID

ZDB-FIG-101111-14

Publication

Tao et al., 2010 - Zebrafish cx30.3: Identification and characterization of a gap junction gene highly expressed in the skin

Other Figures

All Figure Page

Back to All Figure Page

Fig. 5

In situ hybridization of Cx30.3 mRNA in embryos. Embryos were stained by whole-mount in situ hybridization with a cx30.3 antisense riboprobe. A,B: Signal was detected (and highlighted with arrows) in 1 days postfertilization (dpf) stage embryos, in the otic vesicle (A) and dorsal fins (B). C-H: At 2 dpf (C,G,H) or 3 dpf (D-F), cx30.3 mRNA signal was readily detected in the skin (C), the inner ear (D), the lateral line (E,G), and the fins (C). F,H: Sense-probe controls are shown.

Expression Data

Gene:	gjb8
Fish:	WT
Anatomical Terms:	dorsal fin inner ear integument lateral line otic vesicle
Stage Range:	Prim-5 to Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
