FIGURE

Fig. S1

ID

ZDB-FIG-101104-46

Publication

Baker et al., 2010 - A direct role for Wnt8 in ventrolateral mesoderm patterning

Other Figures

All Figure Page

Back to All Figure Page

Fig. S1

Wnt8 is not required for BMP signaling activity after gastrulation. Images of anti-phosphorylated Smad1/5 staining at the 5-6-somite stage. Genotypes are indicated above each row. Arrows indicate tail domain where nuclear P-Smad1/5 indicates active BMP signaling. Lateral views, dorsal right, anterior up. Note absence of staining in tailbud of wnt8 morphant (B), elevated staining in chordin morphant (C), and strong staining in wnt8;chordin double morphant (D).

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
