Fig. S10

Overexpression of wnt5a/5b and wnt11/11r does not rescue tkk or dorsalize the tkk embryos. (A-J) wnt5a, wnt5b, wnt11 and wnt11r RNAs (300 pg) were injected into 1-cell stage wild-type (A,C,E,G,I) and tkk (B,D,F,H,J) embryos just after fertilization in the indicated combinations. Expression of dharma (dha) was examined at the late blastula stage (4 hpf, sphere stage). Animal pole views with dorsal to the left. Scale bars: 200 μm.
