FIGURE

Fig. 6

ID

ZDB-FIG-090826-8

Publication

Santoro et al., 2009 - Characterization of vascular mural cells during zebrafish development

Other Figures

All Figure Page

Back to All Figure Page

Fig. 6

Vascular mural cells derive from the lateral plate mesoderm but not from the blood or endothelial lineages. Confocal images of transverse sections, at different magnifications, of 80 hpf Tg(flk1:GFP)^s843 wild-type (a and d) or cloche (clo^s5) (b and e) or hands-off (han^s6) (c and f) mutant larvae analyzed for Transgelin expression (red). While wild-type (wt) and clo^s5 mutant larvae show Transgelin-positive cells around both the dorsal aorta and visceral organs, han^s6 mutant larvae completely lack both vascular and visceral MCs. Sections are at the level of the1st-2nd somite. Scale bars, 20 μm. NT, neural tube; DA, dorsal aorta; SB, swim bladder; G, gut; MA, mesenteric artery.

Expression Data

Antibody:	Ab1-tagln
Fish:	s843Tg Df(Chr01:hand2)s6/s6; s843Tg npas4l^s5/s5; s843Tg
Anatomical Term:	vascular associated smooth muscle cell
Stage:	Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	Df(Chr01:hand2)s6/s6; s843Tg
Observed In:	vascular associated smooth muscle cell
Stage:	Protruding-mouth

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Mechanisms of Development, 126(8-9), Santoro, M.M., Pesce, G., and Stainier, D.Y., Characterization of vascular mural cells during zebrafish development, 638-649, Copyright (2009) with permission from Elsevier. Full text @ Mech. Dev.
