FIGURE

Fig. 9

ID

ZDB-FIG-071005-27

Publication

Tsai et al., 2005 - Role of Yes kinase during early zebrafish development

Other Figures

All Figure Page

Back to All Figure Page

Fig. 9

Morphology of the PP2-treated embryos. Fertilized eggs (3 min postinsemination) were treated with 4 μM PP2, or PP3 as a control for 5 h. Embryos resulting from eggs treated with PP2 exhibited normal morphology at the high/sphere stage (a) but they exhibited a range of defects involving failure of epiboly (b). Embryos treated with PP3 exhibited normal development (c–d).

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 277(1), Tsai, W.B., Zhang, X., Sharma, D., Wu, W., and Kinsey, W.H., Role of Yes kinase during early zebrafish development, 129-141, Copyright (2005) with permission from Elsevier. Full text @ Dev. Biol.
