Fig. 4

Aberrant neuronal cell development in the absence of Delta-Notch signaling, or Ngn1. A: At 24 hours postfertilization (hpf), lateral view of wild-type embryo. Inset: High-magnification dorsal view of the spinal cord. B: 1G5z expression pattern in mibta52b mutant. Inset: High-magnification dorsal view of the spinal cord. C-F: At the 24 hpf. C: Dorsal view of uninjected control embryo. 1G5z transcripts are detected in trigeminal ganglion (asterisk) and anterior hindbrain (arrow). D: ngn1 mopholino (MO) -injected embryo. Note the complete lack of 1G5z expression in the trigeminal ganglion (asterisk) and anterior hindbrain (arrow). E,F: Lateral view of medial-caudal trunk of the same embryos of C and D. Note that ngn1 MO injection abolished 1G5z expression in the posterior sensory neuronal cells (arrowhead). Arrows indicate interneurons. IN, interneuron; SN, sensory neuron.

Expression Data
Gene:
Fish:
Knockdown Reagent:
Anatomical Terms:
Stage: Prim-5

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
