FIGURE

Fig. 1

ID

ZDB-FIG-051220-1

Publication

Ando et al., 2005 - Lhx2 mediates the activity of Six3 in zebrafish forebrain growth

Other Figures

All Figure Page

Back to All Figure Page

Fig. 1

Expression of lhx2 and lhx9 mRNA in the zebrafish embryo. (A) Expression of lhx2 in the presumptive forebrain at the early somitogenesis stage (11 hpf) (A), at 24 hpf (B) and at 32 hpf (C, D). (E–H) Expression of lhx9 in the zebrafish brain at the same stages as A–D. (A–C, E–G) Dorsal views, anterior up; (D, H) lateral views, anterior left, dorsal up. t, telencephalon; ov, optic vesicles; white arrowhead (C) and e (D), epiphysis; black arrowheads, hindbrain segments; asterisk, mid–hindbrain boundary. (I) Double labeling of lhx9 expression (purple) and primary neurons (brown) by in situ hybridization and α-Tb immunostaining in a 30-hpf embryo. poc, postoptic commissure; TPOC, the tract of the postoptic commissure; arrowheads, complementally localization of lhx9-expressing cells and the reticulospinal neurons in the hindbrain. Scale bar, 100 μm.

Expression Data

Genes:	lhx2b lhx9
Fish:	WT
Anatomical Terms:	diencephalon epiphysis forebrain neural keel midbrain hindbrain boundary optic cup optic stalk postoptic commissure retina rhombomere telencephalon
Stage Range:	1-4 somites to Prim-15

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 287(2), Ando, H., Kobayashi, M., Tsubokawa, T., Uyemura, K., Furuta, T., and Okamoto, H., Lhx2 mediates the activity of Six3 in zebrafish forebrain growth, 456-468, Copyright (2005) with permission from Elsevier. Full text @ Dev. Biol.
