Fig. 2

Embryonic expression of Zangptl1. Whole-mount in situ hybridization was done with a Zangptl (A–D) probe or a myoD probe (E–F) at 24hpf. Weak expression in the somites of a 24hpf embryo especially at the middle portion of tail (arrows in A) was detected. Higher magnification dorsal–ventral (B) and lateral views (C) of a 24hpf embryo are shown. Arrowheads indicate Zangptl1 expression in the somites. (D) A sagittal section of a 24hpf embryo at the middle portion of tail. As comparison of Zangptl1 expression, dorsal–ventral (E) and lateral views (F) of a 24hpf embryo stained with myoD are shown. Arrowheads, somites; sc, spinal cord; nc, notochord. Bar indicates 50 μm.

Expression Data

Genes:	angptl1a myod1
Fish:	WT
Anatomical Terms:	myotome sclerotome
Stage:	26+ somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 5(5), Kubota, Y., Oike, Y., Satoh, S., Tabata, Y., Niikura, Y., Morisada, T., Akao, M., Urano, T., Ito, Y., Miyamoto, T., Watanabe, S., and Suda, T., Isolation and expression patterns of genes for three angiopoietin-like proteins, Angptl1, 2 and 6 in zebrafish, 679-685, Copyright (2005) with permission from Elsevier. Full text @ Gene Expr. Patterns
