FIGURE SUMMARY
- Title
-
Pax2 is expressed in a subpopulation of Müller cells in the central chick retina
- Authors
- Boije, H., Ring, H., López-Gallardo, M., Prada, C., and Hallböök, F.
- Source
- Full text @ Dev. Dyn.
Pax2 labeling in the zebra fish retina. A: Epifluorescence micrograph from a whole section of adult retina showing Pax2 labeling. Arrows indicate the limits of the central Pax2 labeling. a,b: Magnifications of the boxed regions in A. a′,b′: The green channel of the boxed regions in (a) and (b). B: Pax2 co-labeling with the Müller cell marker glutamine synthetase (GS). Arrows indicate Pax2, GS double-positive cells. ONL, outer nuclear layer; INL, inner nuclear layer; GCL, ganglion cell layer. Scale bar = 25 μm in B (applies to (a) and (b)). EXPRESSION / LABELING:
|
