Title: Embryonic and Larval Expression Patterns from a Large Scale Screening for Novel Low Affinity Extracellular Protein Interactions
Authors: Thisse, B., Wright, G.J., Thisse, C.
Source
Submitted By: Thisse, Bernard, Thisse, Christine, Wright, Gavin J. (Citing this work)
Probe: cssl:d228 Quality:
Supplier

Fig. 1

no expression

EXPRESSION / LABELING:

Gene:	bcam
Fish:	AB/TU
Stage Range:	50%-epiboly to Bud

Expression / Labeling details

Fig. 2

notochord, anterior adaxial cells, weak in epidermis (anterior and posterior epidermis), Kupffer’s vesicle

EXPRESSION / LABELING:

Gene:	bcam
Fish:	AB/TU
Anatomical Terms:	adaxial cell axial mesoderm ectoderm Kupffer's vesicle
Stage Range:	1-4 somites to 10-13 somites

Expression / Labeling details

Fig. 3

epidermis, notochord, ventral and dorsal part of the chordo-neural hinge, weak in somites, presumptive branchial arches, dorsal part of the MHB, dorsal diencephalon, heart primordia

EXPRESSION / LABELING:

Gene:	bcam
Fish:	AB/TU
Anatomical Terms:	chordo neural hinge diencephalon ectoderm heart primordium midbrain hindbrain boundary notochord pharyngeal arch somite
Stage:	14-19 somites

Expression / Labeling details

Fig. 4

part of telencephalon, dorsal diencephalon, MHB, heart, pharyngeal pouches, nuclei in hindbrain (one per rhombomere), epidermis, caudal notochord, hypochord, lateral line primordia, anterior ventral diencephalon, lens, pronephros (glomeruli and anterior pronephric ducts), pectoral fin bud, otic vesicle

EXPRESSION / LABELING:

Gene:	bcam
Fish:	AB/TU
Anatomical Terms:	diencephalon epidermis heart rudiment hindbrain lateral line system midbrain hindbrain boundary notochord otic vesicle pectoral fin bud pharyngeal arch pronephric duct pronephros solid lens vesicle telencephalon
Stage Range:	20-25 somites to Prim-5

Expression / Labeling details

Fig. 5

not spatially restricted
part of telencephalon, dorsal diencephalon, MHB, heart, pharyngeal pouches, nuclei in hindbrain (one per rhombomere), epidermis, caudal notochord, hypochord, lateral line primordia, anterior ventral diencephalon, lens, pronephros (glomeruli and anterior pronephric ducts), pectoral fin bud, otic vesicle

EXPRESSION / LABELING:

Gene:	bcam
Fish:	AB/TU
Anatomical Terms:	diencephalon epidermis heart tube hindbrain hypochord lateral line system lens midbrain hindbrain boundary notochord otic vesicle pectoral fin pharyngeal arch pronephric duct pronephros telencephalon
Stage Range:	Prim-15 to Prim-25

Expression / Labeling details

Fig. 6

not spatially restricted
telencephalon, ventral diencephalon, ganglion cell layer of retina, tectum, dorsal posterior tegmentum, pharyngeal endoderm, heart, MHB, dorso-lateral hindbrain, median fin fold, epidermis of pectoral fin, posterior hypaxial muscles, otic vesicle

EXPRESSION / LABELING:

Gene:	bcam
Fish:	AB/TU
Anatomical Terms:	diencephalon heart hindbrain hypaxial myotome region median fin fold midbrain hindbrain boundary musculature system optic tectum otic vesicle pectoral fin pharynx retinal ganglion cell layer tegmentum telencephalon
Stage Range:	High-pec to Long-pec

Expression / Labeling details
