Figure S10.
- ID
- ZDB-IMAGE-260530-36
- Publication
- Pirzada et al., 2026 - Loss of U11/U12 spliceosome gene ZCRB1 leads to aberrant ciliogenesis and WNT signaling
- All Figures
- Figures for Pirzada et al., 2026
|
Figure Caption
Figure S10.
Validation of sgRNA generation of indels in the zebrafish model.
(A) Fragment analyzer analysis of individual zebrafish crispant embryos injected with sgRNA #3 versus a Cas12a-injected WT (control). (B) Sanger sequencing of sgRNA #1–injected embryos demonstrates the generation of varying sizes of indels.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Life Sci Alliance
