ZFIN Image: Cho et al., 2025, Figure 3


Figure Caption

Figure 3

The plasma antioxidant status of adult zebrafish injected with carboxymethyllysine (CML) with or without the banaba leaf extract. (A) Quantification of the lipid peroxidation assessed by thiobarbituric acid reactive substance (TBARS) assay using malondialdehyde (MDA) as the standard. (B) Ferric ion reduction assay (FRA). (C) Sulfhydryl content quantification. (D) Paraoxonase (PON) activity assay. Each analysis was performed using triplicate experiments with duplicate samples, resulting in a total of six replicates (n = 6). * (p < 0.01), ** (p < 0.01), and *** (p < 0.001) displayed the statistical difference between the groups with respect to the group injected with 3 mM CML+50% EtOH; ns represents a non-significant (p > 0.05) difference.
