FIGURE 1

ID

ZDB-IMAGE-240503-26

Genes

cobll1a

Source

Figures for Zeng et al., 2024


Figure Caption

FIGURE 1

Expression pattern of cobll1a. (A–H) Spatio-temporal expression profile of the cobll1a gene detected by in situ hybridization in embryos. (A–C)cobll1a is expressed at the one to eight cell stages. (D)cobll1a is ubiquitously expressed at 12 hpf. (E)cobll1a is expressed in the head. (F, G)cobll1a was expressed in the notochord at 24 hpf and 36 hpf. (H)cobll1a is expressed in the eye, brain, liver and digestive system in 72 hpf embryos. (I) Using 18S as the reference gene, RT-qPCR results demonstrated the relative expression of the cobll1a at different stages.

Figure Data

Expression / Labeling details
