Fig. 6.

ID: ZDB-IMAGE-231002-319
Publication: Leino et al., 2023 - Zbtb16 mediates a switch between Fgf signalling regimes in the developing hindbrain
All Figures: Figures for Leino et al., 2023


Figure Caption

Fig. 6.

Partial rescue of the Zbtb16 mutant phenotype by Fgf3 knockdown. (A-B′) Colorimetric ISH for etv5b in sibling control (n=88) and zbtb16a^−/−;zbtb16b^−/− (n=40) embryos injected with standard control+p53 MO. (C-D′) ISH for etv5b in sibling control (n=83) and zbtb16a^−/−;zbtb16b^−/− (n=35) embryos injected with Fgf3 translation blocking MO+p53 MO. Three independent experiments. Dorsal views of the hindbrain, wholemount. r, rhombomere. Scale bars: 50 µm.
