Figure 4—figure supplement 1—source data 1.

ID: ZDB-IMAGE-230818-21
Publication: Hagio et al., 2023 - Optogenetic manipulation of Gq- and Gi/o-coupled receptor signaling in neurons and heart muscle cells
All Figures: Figures for Hagio et al., 2023


Figure Caption

Figure 4—figure supplement 1—source data 1. Effect of trial number on heartbeats (HBs).

(A) Average relative HB frequency of larvae expressing MosOpn3 (n=7 for trial 1; n=2 for trial 6), PufTMT (n=5 for trial 1; n=3 for trial 6), and LamPP (n=4 for both trials 1 and 6) in cardiomyocytes. The heart area of Tg larvae was irradiated with light (520 nm for MosOpn3, 470 nm for PufTMT, and 405 nm for LamPP) at 0.5 mW/mm² for 1 s at the indicated period. The statistical analysis employed the linear mixed effects model. Shading indicates SEM. (B, C) Latency to cardiac arrest (B) and time to resumption of HBs (C) in trials 1 and 6. Four larvae for each Tg line were analyzed. There were no significant differences in latency or time to resumption between trials 1 and 6 of MosOpn3, PufTMT, and LamPP. Student’s t-test, * p<0.05; ns, not significant.

Figure 4—figure supplement 1—source data 1.Data for <xref rid='fig4s1' ref-type='fig'>Figure 4—figure supplement 1</xref>, effect of trial number on HBs.
