Figure Caption
Fig. 5
Both nrp2a and nrp2b act in the same pathway with sema3fa. A. Representative confocal sections of sema3fa mutant and nrp2a;sema3fa double mutant siblings. Yellow arrows indicate misprojecting axons. B. The misprojection phenotype in nrp2a;sema3fa double mutants is not significantly different from sema3fa mutant siblings. C. Representative confocal sections of sema3fa mutant and nrp2b;sema3fa double mutant siblings. Yellow arrows indicate misprojecting axons. D. The misprojection phenotype in nrp2b;sema3fa double mutants is not significantly different from sema3fa mutant siblings
