ZFIN Image: Blanco-Sánchez et al., 2020, Fig s5


Figure Caption

Fig s5 sox10+ olig2+ oligodendrocyte population recovers in mz ypel3 mutants. (A, B) Lateral views at the level of the spinal cord from somites 8 to 11 of 80 hpf larvae. WT and mz ypel3 mutant embryos were photoconverted at 26 hpf and then imaged at 80 hpf. As expected, primary motoneurons are labelled magenta (arrowhead). Newly added cells are labeled green (Tg[olig2:kaede]). Oligodendrocytes are colabeled with Tg[olig2:kaede]) and Tg[sox10:mRFP] (arrows in A and B). (C) Quantification of the average total number of sox10+, olig2+ oligodendrocytes at 80 hpf in WT and mz ypel3-/- mutants. (D) Quantification of the average total number of nkx2.2+, sox10+ oligodendrocytes at 7 dpf.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ PLoS Genet.
