Figure EV2

ID: ZDB-IMAGE-210714-43
Publication: Jamalpoor et al., 2021 - Cysteamine-bicalutamide combination therapy corrects proximal tubule phenotype in cystinosis
All Figures: Figures for Jamalpoor et al., 2021


Figure Caption

Figure EV2 Decreased retention of mTOR on the lysosomal membrane of cystinotic cells

Representative immunofluorescent staining of CTNS^WT, CTNS^−/− and CTNS^Patient co‐immunolabelled with lysosomal‐associated membrane protein 1 (LAMP1; green) and mTOR (Red) (n = 3). Merge images with zoomed areas are representative of the localization of mTOR with lysosomes in various experimental conditions. Scale bars are 10 µm.
