ZFIN Image: Nerli et al., 2020, Figure 2—figure supplement 1


Figure Caption

Figure 2—figure supplement 1—source data 1. Depth of basal translocation is not linked to sister cell fate.

(A) Maximum basal position of Ath5- and Ath5+ cells. Unpaired t-test with Welch’s correction. (B) Integral mean of Ath5- and Ath5+ cells. Vertical bars represent standard deviation. Kolmogorov-Smirnov test. (C) Directionality ratio of Ath5+ and Ath5- progenitors cell soma for basal translocation. Data from Figure 2D–E. Error bars represent SEM. (D) Average velocity of Ath5+ and Ath5- cell bodies between 0 and 100 min, corresponding to basal translocation. Vertical bars represent standard deviation. Unpaired t-test. (E) Comparison between maximum basal position of sister cells in control (purple dots) and dynactin dominant negative (dynactin DN, cyan dots) from Figure 2B and K, respectively. Line connects sister cells.

Figure 2—figure supplement 1—source data 1.Source data for panels B, C and D of <xref rid='fig2s1' ref-type='fig'>Figure 2—figure supplement 1</xref>.
