Figure Caption
Fig. 3 Live imaging of 5 dpf lws:PAC(H) lws reporter transgenic confirms a switch from lws2 to lws1 in individual cones in response to TH (T3). Imaging was conducted for 9 h starting 8 h after treatment with 100 nM T3 began. Time stamps indicate hours from start of imaging. Arrowheads show 2 RFP+ (lws2+) cones switching to express GFP (lws1) over the time of imaging. Cells move to the left of the region of interest due to growth of the larva. (Scale bar, 10 μm.)
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Proc. Natl. Acad. Sci. USA
