ZFIN Image: Clément et al., 2018, Fig. 1


Figure Caption

Fig. 1

The pillars do not form properly in cog4^−/− mutants. Live images of the inner ear of cog4^+/+ sibling (A, n = 34 larvae) and cog4^−/− mutant larvae (B, n = 15 larvae). Red stars indicate the semicircular canals. Phalloidin staining of the inner ear of cog4^+/+ sibling (C, n = 24 larvae) and cog4^−/− mutant larvae (D, n = 25 larvae). Yellow arrowheads indicate the fusion plates that form in 100% (24 out of 24) of wild-type siblings (C). Red arrowhead points to the malformed pillar. One or more malformed pillars are observed in 84% (21 out of 25) of homozygous mutant larvae (D). Anterior to the left and dorsal to the top. 5 dpf.

Figure Data

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Mechanisms of Development, 155, Clément, A., Blanco-Sánchez, B., Peirce, J.L., Westerfield, M., Cog4 is required for protrusion and extension of the epithelium in the developing semicircular canals, 1-7, Copyright (2018) with permission from Elsevier. Full text @ Mech. Dev.
