Figure Caption
Fig. S9
FGF signaling is not altered in rw341 mutant lenses
(A, B) Ventral (A) and lateral (B) views of wild-type and rw341 mutant heads labeled with pea3 RNA probe. Lower panels show the eye. pea3 mRNA is expressed along the circumference of the lens equator in wild type (yellow arrowheads). The spatial expression pattern of pea3 mRNA is not changed in rw341 mutants (yellow arrowheads).
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
