ZFIN Image: Gu et al., 2017, Fig. 4


Figure Caption

Fig. 4

Transient terfenadine treatment impaired cardiac contraction, resulting in HF. (A) Representative images of control (0.001% DMSO) or terfenadine (20 μM)-treated zebrafish larva. (B) Lateral view of zebrafish larvae at 4 dpf. The control zebrafish (0.001% DMSO) exhibited normal cardiac morphology, whereas terfenadine (20 μM)-treated zebrafish larvae showed pericardial edema (blue circle) and venous congestion (green circle). (C) Quantification of ventricular FS in control (0.001% DMSO) and terfenadine (20 μM)-treated zebrafish larvae. Ventricle size of control (0.001% DMSO) and terfenadine (20 μM)-treated zebrafish larvae after a 24 hours treatment. n=20 zebrafish/group, scale bar=0.5 mm.

a = Atrium; DMSO = dimethyl sulfoxide; dpf = days post fertilization; FS = fractional shortening; HF = heart failure; V = ventricle.

^*p<0.050; ^†p<0.010.

Figure Data

Phenotype details
