ZFIN Image: Furlan et al., 2017, Fig. s7


Figure Caption

Fig. s7

Compared localization of GABA and Glutamatergic neurons with the position of neurons born at 5dpf in the adult pallium, related to Fig.7. A-B’: Cross-sections at median pallial levels of her4^{H2a-mCherry,9TB(5dpf)} brains observed at 3mpf (confocal microscopy, single 70μm stacks), immuno-processed for mCherry and stained by in situ hybridization with the following probes: gad65/67a/67b (gad, A’) and vglut1/2.1/2.2 (vglut, B’). A, B: fluorescence channels; A’, B’: superimposed bright field and fluorescence channels; red arrows in A, B indicate the shape of the mCherry-positive domains and white dotted lines line the pallial contour. Insets are high magnifications of the boxed areas showing mCherry in the nucleus of gad- or vglut-positive neurons. Scale bar: 70 μm.
