Figure Caption
Fig. 1
Effect of rhein on immune cell migration in tail-cutting-induced inflammation in zebrafish.
Notes: The zebrafish larvae were incubated with different concentrations of rhein following tail cutting. Representative photographs showing the fluorescence images of tail-cutting-induced immune cell migration of zebrafish larvae, 100× magnification (A) and a bar graph showing quantitative data analysis (B). Experiments were performed in triplicate, and the data are expressed as mean ± SEM. (*P<0.01 vs LPS; analysis of variance).
Abbreviations: SEM, standard error of the mean; LPS, lipopolysaccharide.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Drug Des Devel Ther
