Figure Caption
Fig. S8
FISH to localize rprm gene expression in zebrafish larvae.
Top panels showing head or trunk views. (A-B) Vascular-specific transgenic Tg(fli1a:EGFP) marks endothelial cells and is revealed with the anti-GFP antibody. (C-F) FISH to detect rprma, rprml and pdgfrβ genes expression. pdgfrβ is used as mural cell marker. (G-H) merged confocal imaging.
