Figure Caption
Fig. S4
rprm expression during brain development in zebrafish embryos.
rprm expression patterns were examined using whole-mount in situ hybridization in wild-type embryos at (A-D) 1 day post-fertilization [hpf]. (A-D) Lateral views. (A-C) At these developmental stages, rprma, rprmb and rprml transcripts are located in neuronal populations such as dorsal thalamus (DT), ventral thalamus (VT) and the cranial placode in the tigreminal ganglia (tg). (D) rprm3 is ubiquitously expressed through the brain.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ PLoS One
