Fig. S2
Decreased transcriptional expression of apical transporters in the pronephric duct of prl-deficient larvae.
Expression patterns were assayed with whole mount in situ hybridization. A, B) Decreased expression of carbonic anhydrase II (ca2) in the pronephric ducts of prl-deficient larvae (B) compared with those of wild-type control fish (A) at 5 dpf in regular culture medium. C, D) Decreased expression of solute carrier family 12, member 10, tandem duplicate 3 (slc1210.3) in the pronephric ducts of prl-deficient larvae (B) compared with those of wild-type control fish (A) at 5 dpf in regular culture medium. Dpf, days post-fertilization.
