ZFIN Image: Sotolongo-Lopez et al., 2016, Fig. S1


Figure Caption

Fig. S1

(A) No changes in green-, UV- and blue-sensitive cone opsin expression in ljr^p23ahub mutants.

Retinal cryosections from WT and ljr^p23ahub embryos at 4 dpf immunolabeled for rods (4C12, red) and the green-, UV- and blue-sensitive cone opsins (green). Nuclei were counterstained with DAPI (blue); dorsal is up. No differences in the number or expression levels are detected for any of the opsin subtypes, except for the increased number of rods in ljr^p23ahub mutants. (B) retinal cryosections from WT and ljr^p23ahub embryos at 4 dpf immunolabeled for ganglion cells (Zn8), amacrine cell (5E11), bipolar cells (PKCα) and rods (4C12). No differences were observed for any labeled retinal cell types.
