Figure Caption
Fig. S6
Inhibition of RhoA affects remodeling of the furrow microtubule array. Embryos were injected with RhoA inhibitor (Rhosin) at one cell stage and at 8-cell inmunolocalization of α-tubulin was performed. (A and B) At 8 cell embryonic stage microtubules from injected embryos with Rhosin are disorganized at the cleavage furrow (n=6) compared to the buffer injected embryos (n=6) where the microtubules showed a perpendicular distribution towards the cleavage furrow in 3 independent experiments.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 421(1), Miranda-Rodríguez, J.R., Salas-Vidal, E., Lomelí, H., Zurita, M., Schnabel, D., RhoA/ROCK pathway activity is essential for the correct localization of the germ plasm mRNAs in zebrafish embryos, 27-42, Copyright (2017) with permission from Elsevier. Full text @ Dev. Biol.
