Fig. 7

Fig. 7

Expression of klf7 and klf6a in the torus longitudinalis, optic tectum, dorsal tegmentum, isthmus, torus semicircularis and anterior medulla of the adult zebrafish brain. Images in the top panels are low magnified (same magnification, scale bar = 200 µm) views of halves of brain sections from levels shown in Fig. 1 (panel A is the same as Fig. 6E). Middle and bottom panels are higher magnified views (C and D have the same magnification, while the remaining panels have the same magnification, scale bar = 100 µm) of portions of their respective images in the top panels. Panels C and D, E and F are torus longitudinalis and optic tectum, respectively. Panels G and H, I and J show dorsomedial tegmentum and torus semicircularis, respectively. See list for abbreviations.
