Figure Caption

Fig. S8

Confocal images of GFP-positive regions external to CNS during the first month of development. A-A′, confocal lateral view of 26 hpf embryo (Z-stack). Reporter gene is activated in the cardiac mesoderm and around the outflow tract. Spare cells are also visible in the yolk ball. B-B′, zoomed heart region of a 26 hpf embryo (Z-stack). C-C′, ventral view of heart and dorsal aorta of a 4 dpf larva (Z-stack). GFP expression in this area is no longer visible beyond this stage. D, zoomed view of the eye of a 48 hpf larva (Z-stack). GFP-positive cells are visible both in retina and lens. E, zoomed view of an olfactory pit of a 6 dpf larva (Z-stack). F-F′, magnified image of the jaw of a 5 dpf larva (Z-stack). Few cells are visible in this area during the early larval development; G, lateral image of a 48 hpf larva: hindbrain, spinal cord and fin bud (white arrowhead). H, zoomed lateral view of the trunk region of a 40 dpf larva, with the correspondent bright field. Reporter expression is still present in the neural tube. Some fibers of the median musculature seem to activate Smad3-mediated signaling during this developmental stage. Scale bar is 100 µm in A-A′, C-C′, F-G; 50 µm in B-B′, H; 20 µm in D; 10 µm in E.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 396(1), Casari, A., Schiavone, M., Facchinello, N., Vettori, A., Meyer, D., Tiso, N., Moro, E., Argenton, F., A Smad3 transgenic reporter reveals TGF-beta control of zebrafish spinal cord development, 81-93, Copyright (2014) with permission from Elsevier. Full text @ Dev. Biol.
