Figure Caption
Fig. S1
Effects of cyp2aa9MO is specific.
(a-b) Translation of cyp2aa9-GFP mRNA was inhibited by cyp2aa9MO, but not conMO. (c-e) cyp2aa9MO did not lead to obvious cell apoptosis as indicated by the co-injection of p53MO, excluding off-target effects of cyp2aa9MO (c, n=30/31; d, n=24/25; e, n=26/27). (f-g) The cyp2aa9 morphants exhibited normal blood circulation under the Tg(gata1:DsRed) background (f, n=24/24; g, n=23/25). c-f, lateral views, anterior left, dorsal top.
