Fig. 5

Spatial localization of rxfp2l transcript in the caudal region of zebrafish larval brain. A–F: Transverse sections of hybridized zebrafish larvae (72 hpf) as indicated in the schematic drawing of the zebrafish larval brain. Black arrowhead indicates restricted rxfp2l-expressing cell cluster in the medulla oblongata. Scale bar: 50 µm. ac, anterior commissure; CC, cerebellar crest; CeP, cerebellar plate; Ch, chorda dorsalis; DT, dorsal thalamus; E, epiphysis; EmT, eminentia thalami; H, hypothalamus; MO, medulla oblongata; N, region of the nucleus of medial longitudinal fascicle; oc, optic chiasma; OV, otic vesicle; P, pallium; Po, preoptic region; poc, postoptic region; S, subpallium; T, midbrain tegmentum; TeO, optic tectum; VT, ventral thalamus.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ J. Exp. Zool. B Mol. Dev. Evol.
