Figure Caption
Fig. S4
Overexpression of Yap S87A in vsx2 positive cells results in ectopic expression of dct mRNA and -2.7kb tfec:Gal4-VP16/dsRed:UAS:Yap S87A positive cells do not migrate into the neural retina.
(A) Endogenous dct expression is observed in the RPE. (B-B′′) Ectopic dct expression is observed in the neural retina and enhanced in the ciliary marginal zone in Yap S87A overexpressing embryos. Black arrows denote ectopic dct. (C-C′′′) RPE cells overexpressing Yap S87A do not ectopically migrate into the neural retina. Images represent a 2 hour time course from 40-42 hpf. White arrows indicate a Yap S87A positive RPE cell.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
