Fig. 8

ID

ZDB-IMAGE-151019-19

Genes

EGFP

Publication

Sztal et al., 2015 - Zebrafish models for nemaline myopathy reveal a spectrum of nemaline bodies contributing to reduced muscle function

All Figures

Figures for Sztal et al., 2015


Figure Caption

Fig. 8

a Maximum projection confocal microscopy images of Tg(ACTA1^wildtype-eGFP)_low and Tg(ACTA1^wildtype-eGFP)_high zebrafish strains injected with two different Nebulin (Neb) morpholinos compared to control uninjected embryos at 2 dpf. There is an increased prevalence of eGFP-positive globular aggregates at the myosepta (arrowheads) in Tg(ACTA1^wildtype-eGFP)_high Neb morphants compared to controls. Knockdown of Neb produces globular aggregates at the myosepta (arrowheads) in Tg(ACTA1^wildtype-eGFP)_low Neb morphants that are absent in control uninjected embryos. b Maximum projection confocal microscopy images of wild-type embryos injected with Neb morpholinos at 2 dpf and stained with phalloidin shows an increase in actin-positive aggregates at the myosepta (arrowheads), which are absent in control uninjected embryos

Figure Data

Expression / Labeling details

Phenotype details
