ZFIN Image: Rydeen et al., 2015, Fig. 3


Figure Caption

Fig. 3

Embryonic RA is decreased in VP-RAR expressing embryos. (A, B) vp-rar mRNA injected into Tg(β-actin:GDBD-RLBD);(UAS:EGFP) embryos shows significant loss of GFP expression indicating embryonic RA is reduced compared to WT. 25% (n=7 of 28) of control embryos from the Tg(β-actin:GDBD-RLBD);(UAS:EGFP) outcrossed to a WT adult showed strong RA sensor expression, while 22% (n=8 of 37) of vp-rar mRNA injected embryos had dramatically reduced RA sensor expression. (C,D) RA levels are greatly diminished after heat-shock induction of the egfp-vp-rar transgene in Tg(β-actin:GDBD-RLBD);(UAS:mCherry) embryos compared to siblings without the heat-shock inducible transgene.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 405(1), Rydeen, A., Voisin, N., D'Aniello, E., Ravisankar, P., Devignes, C.S., Waxman, J.S., Excessive feedback of Cyp26a1 promotes cell non-autonomous loss of retinoic acid signaling, 47-55, Copyright (2015) with permission from Elsevier. Full text @ Dev. Biol.
