Figure Caption
Fig. S5
Effect of RGD treatment on pFAK distribution in the interrenal region.
Transverse sections of Tg(kdrl: GFP)s843 embryos either untreated (control; n = 6) or treated with 100 µM RGD peptide (n = 10) from 26 hpf and harvested at 2.5 dpf for evaluation of 3β-Hsd activity and pFak level by IHC. Sections are shown of a representative embryo from each group, oriented with the dorsal side at the top. Abbreviations: interrenal tissue (IR), notochord (NC), somite (S).
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ PLoS One
