Figure Caption
Fig. S3
Mo1-neurod1 and Mo2-neurod1 morpholinos efficiently block the expression of GFP from the neurod1: egfp transgenic line. Lateral views of 26 to 30 hpf tg(neurod1:egfp) embryos injected with Mo1-neurod1 (A), Mo2-neurod1 (B) or control morpholinos analyzed by bright field illumination (A,B) or by epifluorescence illumination (A′,B′) showing that both morpholinos efficiently block the expression of GFP from the neurod1:egfp transgenic line [40] without disturbing the general morphology of the embryos.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ BMC Biol.
