ZFIN Image: Neumann et al., 1999, Fig. 9


Figure Caption

Fig. 9 Larval pectoral fin endoskeleton formed in wild-type and syu mutants. Alcian blue stains of the pectoral girdle and fin of larvae on day 6. (A) Wild-type pectoral fin endoskeleton. (B) syu hypomorphic allele tq252. (C) syu null allele t4. syu null mutants do not form any elements of the fin endoskeleton and show a reduced cleithrum (cl). syu^tq252 hypomorhic mutants variably show reductions of the fin endoskeleton and are able to form all elements including the scapulocoracoid (sco), endoskeletal disc (ed) and the actinotrichs (ac), but show a reduction in cell number, which is most apparent in the endoskeletal disc. ac, actinotrichs; cl, cleithrum; ed, endoskeletal disc; sco, scapulocoracoid.
