Fig. S11

ID
ZDB-IMAGE-131218-9
Source
Figures for Sittaramane et al., 2013
Figure Caption

Fig. S11 Aberrant chemokine gene expression in putative detour mutants
(A-D) Dorsal views of the hindbrain region, with anterior to left, in 7-somite stage embryos obtained from a detour te370a/+ incross, processed for in situ hybridization with cxcr7b (A,B) or cxcl12a (C,D). Whereas most embryos (A,C) showed normal expression of these genes in the hindbrain and sensory neurons (arrowheads), some (B,D) exhibited defects (arrowheads). However, sequencing of the gli1 locus that is mutated in the dtr te370a allele did not show linkage between the defective phenotype and the dtr-/- genotype. Nonetheless, it remains formally possible that inefficient migration of FBM neurons in detour mutants results from reduced chemokine signaling.
