Figure Caption
Fig. S3
Expression of arterial and venous markers in notch3 mutant larvae. Patterns of the arterial marker, A-C) (efnb2a: 3 wt, 9 hets, 4 mutants), D-F) deltaC (dlc: 1 wt, 8 hets, 6 mutants) and venous, G-I) fms-related tyrosine kinase 4 (flt4: 2 wt, 10 hets, 2 mutants) and J-L) disabled homolog 2 (dab2: 2 wt, 9 hets, 3 mutants) expression were indistinguishable between A,D,G,J) wild-type, B,E,H,K) notch3zm/+ and C,F,I,L) notch3zm/zm mutants at 28 hpf. A-L) Dorsal is to the top and the orientation of the Anterior (A) and posterior (P) axis is as indicated. DA denotes dorsal aorta, CV indicates the cardinal vein.
