ZFIN Image: Dranow et al., 2013, Fig. S3


Figure Caption

Fig. S3 Gonads from sex-reverted Tg(ziwi:CFP-NTR) females contain testis-like tissue. (A) Ovaries of control DMSO-treated females have many large, yolky oocytes. (B) Gonads of Mtz-treated sex-reversed fish contain mostly adipose tissue with patches of opaque testis-like tissue, most similar to the testes of a control male (E). (C, D, F, G) Fluorescent micrographs of the gonad of an Mtz-treated 1° female and testes of control male with CFP pseudocolored in green. (C) Gonads from Mtz-treated females contain patches of CFP-positive cells that resemble control testis tissue (F). (D, G) Magnified views of the boxed regions in C and F, respectively.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 376(1), Dranow, D.B., Tucker, R.P., and Draper, B.W., Germ cells are required to maintain a stable sexual phenotype in adult zebrafish, 43-50, Copyright (2013) with permission from Elsevier. Full text @ Dev. Biol.
