Fig. 6

ID

ZDB-IMAGE-130502-36

Genes

EGFP
mRFP

Publication

Saxena et al., 2013 - Sox10-dependent neural crest origin of olfactory microvillous neurons in zebrafish

All Figures

Figures for Saxena et al., 2013


Figure Caption

Fig. 6 Photo-morpholino knockdown of Sox10 demonstrates its necessity during the ingression/differentiation process.

(A) and (A′) Control (antisense morpholino + sense photo-morpholino injected but not photocleaved) live embryos have robust numbers of ciliated (red) and neural crest–derived microvillous (green) neurons at 38 hpf. In contrast, identically injected embryos subjected to photocleavage at 24 hpf go on to develop ciliated neurons but significantly lack microvillous neurons at 38 hpf (B and B′) in comparison to control embryos. Sox10:eGFP: green; OMP:RFP: red. Orientation arrows: D: dorsal; V: ventral; L: lateral. Scale bars: 30 μm. See also Figure 6—figure supplement 1.

Figure Data

Expression / Labeling details

Phenotype details
