Figure Caption
Fig. S2
Partial colocalization between tyrosine hydroxylase (TH) and cdh23 was observed in the ventral tegmentum. A: Combined cdh23 in situ hybridization (left panel) and anti-GFP antibody labeling (middle panel) shows that cdh23 is not expressed in pax6p-GFP-positive amacrine cells (overlay, right panel). B: Cdh23 is also not expressed in calretinin-positive amacrine cells. C: In the ventral thalamus, a subset of the bilateral deep diencephalic cdh23-positive cells (corresponding to the area shown in Figure 2J) label with anti-TH, which marks the dopaminergic neurons of the ventral tegmentum.
